TDB 127
R-1
TT
Construction
Radial
Machinery
Tractor
Application
Agriculture
Optimized Lug Spacing (Void ratio)
- Outstanding self-cleaning properties due to exclusive tread geometry
Extra Deep Tread
- Longer tire life
Unique Tread Design
- Maximum traction on wet soil
- Used in utility tractors and rototillers
Center Tie Bar
- Reduces lug shuffling in operation/service
- Strong lug base ensures less damage to the lugs
CCR Tread Compound
- Minimizes wear/tear in operations/service
- Better durability
- Ensure cut & chip resistance in operation/service
TDB 127
| SKU | Size | ALT Size | LI/SI | Ply/* | Type | Tread Depth (32 nds) | Preferred Rim | Wt (lbs) | Unloaded Dimension | RC | SLR | Psi | Max Load at 6 mph (lbs) | Max Load at 15 mph (lbs) |
|
| SW | OD | ||||||||||||||
| mm | mm | mm | mm | ||||||||||||
| in | in | in | in | ||||||||||||
| 3001030181 | 180/85D12 | - | 76A6/72A8 | 6 | TT | 34 | 5.00 | 23 | 165 | 612 | 1830 | 279 | 35 | 1170 | 780 |
| 7 | 25 | 72 | 11 | ||||||||||||
